1.5 Replaceable Integrated Air Filter

Replaceable Integrated Air Filter

※Product Features

1. Aluminum profile static pressure box, embedded with mini-pleat fine efficiency air filter;

2. Optimal ventilation,attractive appearance,convenient installation&maintenance,light investment, light weight,thin thickness,fine efficiency.

※Application Field

Widely used in operating rooms,laboratories,pharmaceutical rooms,microelectronics facilities,film and optical fiber equipment manufacturing and food processing plant, which has a higher requirement about cleanness.

※Material Composition and Running Condition

Filter element:ultra fine glass fiber filter paper

Main box frame:aluminum profile

Back cover of box:aluminum sheet/ zinc-coated steel sheet

Air filter frame:aluminum profile(T=69mm)

Sealant:two-component polyurethane adhesive

Sealing strip:EVA/ Neoprene

Separator:polyolefin hot-melt adhesive

Filtration Efficiency:99.99%~99.999%@0.3μm

Available thickness(mm) of aluminum profile frame:150,180

Max.temperature applicable: 70℃

Max.humidity applicable: 100%

※Size&Data

Besides the size above, custom size acceptable.
